Remote Site Security

Implementing Power Visibility for Off-Grid Solar Hybrid Sites using the SiteBoss Site Controller

Summary: Mountaintops and other higher altitude locations are excellent places to locate telecom sites due to the vast distances that can be covered from a single point. At the same time, mountaintops are difficult-to-reach sites locations that can make monitoring and service visits highly expensive, time-consuming, and even impossible during certain times of the year.  Often AC grid power at these sites is impractical and some other power source needs to be provisioned. Asentria began working with a North American mobile network operator to address issues for remote sites that had no grid power available.

This technical case study goes into technical details of how this solution was implemented for this customer and what technical features of the SiteBoss were used in order to achieve the project objectives.

Case Study Introduction

Public safety networks have somewhat different needs than other networks. Especially in a large region with high temperatures like in the Middle East, network resiliency is a paramount concern. One of the main concerns with country-wide deployment is the fact that some sites can be located in extremely remote and distant locations that can be accessed only with great difficulty. The risk is that in the case of a power loss, it may take some time for a field service team to reach the site which means that implementation of backup power sources is of utmost importance.

Customer challenge

Initially, the client had some minor operational issues with their network and reached out to Asentria for assistance for a quick fix. But as soon as the client realized Asentria’s true potential and capabilities, they decided to expand the project and started asking the team to integrate more of Asentria’s technology devices into their equipment.

Later on, as the client was moving further with their plans of integrating sites in a country-wide deployment, they realized that Asentria offered solutions to problems they didn’t think had a reasonable solution. Some of those sites were in extremely remote and distant locations which meant that in the event of a power loss, the affected site would have to operate on backup power sources as long as possible until a fix could be implemented. A primary concern was then to find new ways to extend the diesel fuel levels at the remote sites.

Project Objectives

• Extend diesel fuel levels at sites
• Improve backup power sources
• Lower operating expenses

Solution

The Asentria engineering team worked with the client to integrate generators and as the client’s operator began to better understand the capabilities of the SiteBoss, a new Telecom Site Automation program was outlined and deployed. The SiteBoss was interfaced to the HVAC system, the generator, and the rectifier. When the site was running on the generator, the site operated similarly to when it was on grid power, with all equipment in operation.

However, when the site was running on batteries, the HVAC system would not operate.  In order to fix this other issue, an automation was created so that the SiteBoss would watch the site temperature and battery discharge levels from the DC rectifier. This meant that the site would operate on batteries as long as the state of charge of the batteries was high enough and the temperature was low enough. Otherwise, the generator would run until batteries hit a high state of charge and the site was sufficiently cool. This cycling enabled diesel fuel levels at a remote site to be considerably extended.

Additionally, the SiteBoss control system could intelligently decide when to use the economizer to bring in cooler outside air. At the same time, the remote access helped operations managers and technicians more easily manage their HVAC systems.

Customer benefits

• Extend site life in cases of primary power loss.
• Secure remote access to on-site equipment interfaces
• Remote control and alarming
• External environmental sensors supplied by Asentria
• Adjunct engineering from Asentria, integrated solution

Summary

This is a Case Study Summary.  A companion Technical Case Study provides substantial technical details as to specifically how the project was accomplished.  You can download load the PDF for that study here:

Introduction

The customer is a North American mobile network operator with remote cabinet sites implemented nationwide. Their plan was to build a very large network, deploying Asentria’s devices as the network itself was deployed. It was a cabinet solution, so Asentria’s products were designed to be integrated into cabinets in an integration facility before being sent to individual locations for deployment. The client’s main interest was in Asentria’s ability to do DC reboot and provide cellular wireless out-of-band coverage.

Customer at a Glance

• Industry: Telecom – Mobile Network Operator
• Location: USA
• Network size: 40,000 sites

Project at a Glance

• No of sites: 18,000 at peak
• Project duration (# of days): 4 years
• Installed products: SiteBoss S571
• Included services: Software Integration and Hardware Development
• Main Benefit: Remote and out-of-band access to cabinet locations via wireless modems.  DC reboot ability. If backhaul is lost, out-of-band connectivity allows for an ability to troubleshoot and reboot.

Download our free case study that provides substantial technical details as to specifically how the project was accomplished:

Executive Summary
Recent weather-related disasters have illustrated both the public’s reliance on cell phones for communicating in emergency situations, as well as the effect of widespread power outages on the cellular network itself. Cellular phones are no longer considered an additional method of communication for many people, instead they are their only means of communicating. The cellular network can be considered an important part of the public safety infrastructure.

This case study describes what occurred to the cellular network in the northeastern United States during recent hurricanes, and the subsequent steps taken by one wireless network operator to improve the management of the backup generators and related systems on their network.
